Powerloop Racing - Spike -V2.0


Price : $ 49.12

Propeller size : None



Description

Powerloop Racing - Spike - 230mm, specifications

  • True X Freestyle frame
  • Propellers up to 5.1
  • 4mm arms
  • Battery: top mount, fit with most of the 1300 -1500 mAh LiPo.
  • Cam plate compatible with Runcam Swift 2 and Foxeer Predator Mini
  • Press nuts for easy arm replacement
  • Vertical plate to fix the VTX and the RX
  • The rear lipo strap goes through the vertical plate, allowing a narrow rear end : better look, less weight, and more fresh air for the rear motor

TPU accessories : HD cam mount, VTX antenna mount, RX antenna mount , crossfire immortal T antenna mount, ...(stl files) are available here:

https://www.thingiverse.com/MLecchi/designs

Informations about the hardware included in the kit:

  • M3x6mm screws: use it for the 6 standoffs on bottom plate and the 2 rear standoffs on the top plate
  • M3x8mm screws: use it for the 4 front standoffs on the top plate. The extra length is here in case you want to mount a HD cam mount in TPU
  • M3x10mm screws: use it for the outer press nuts
  • M3x12mm screws; use it for the inner press nuts
  • No Nylon hardware included. If needed, you can add parts to your cart from the "Hardware " Category in the left menu .
  • M3x12mm screws can be replaced by longer screws (hardware category in the left menu) depending on the type of nylon hardware you want to use for the FC and ESC or PDB (12mm screws are recommended for M/F nylon standoffs, longer screws are recommended for F/F nylon standoffs)

Please feel free to contact us on facebook or directly via Armattan productions!

https://www.facebook.com/PowerloopRacing/
