GM RTR 5inch Freestyle Frame
Price :
$
50.63
Propeller size :
5"
Item List
-
GM RTR Top Plate 2mm
Quantity :1
-
GM RTR Arm 5mm
Quantity :4
-
GM RTR Meteplate 2mm
Quantity :1
-
GM RTR Bottom plate 2mm
Quantity :1
-
GM RTR Bottom X
Quantity :1
-
20mm M3 F/F Alumi Tapped Stepped Standoff Black Anodized 5.5mm O.D.
Quantity :8
-
M3 Stainless Steel Sunk Nuts (per piece)
Quantity :5
-
6mm M3 Steel Button Head Bolt Black Anodized
Quantity :10
-
10mm M3 Steel Button Head Bolt Black Anodized
Quantity :1
-
8mm M3 Steel Button Head Bolt Black Anodized
Quantity :4
-
12mm M3 Steel Button Head Bolt Black Anodized
Quantity :4
Description
You also need SOCKET HEAD screws for the stack (22mm maximum length). Not included in the kit.
Rivet holes might need some filing to fit properly, depends of the CNC tolerance.
Screws goes like this:
m3x6 x 10 (top + bottom plate)
m3x8 x 4 (xplate arm)
m3x10 x 1 (xplate center)
m3x12 x 4 (arm-standoff)
